Home  > PRODUCT  > Customized Kiosk Solution  >  19 Inch Touch Screen Network Self Service Ordering Payment Kiosk
19 Inch Touch Screen Network Self Service Ordering Payment Kiosk
19 Inch Touch Screen Network Self Service Ordering Payment Kiosk
Overview
Quick Details
Place of Origin:
Guangdong, China
Brand Name:
Customized
Model Number:
HZ-KT073
Product Name:
19 Inch Touch Screen Network Self Service Ordering Payment Kiosk
Function:
Payment Terminal
Touch screen type:
Capacitive Touch
Application:
Indoor
Main components:
Touchscreen
Optional parts:
Barcode Reader
Kiosk color:
Customer's Request
Power supply:
110-240V 50HZ/60HZ
Touch Screen:
15/17/19/22"
Color:
Client's Requests
Supply Ability
Supply Ability:
1000 Unit/Units per Month

19 Inch Touch Screen Network Self Service Ordering Payment Kiosk

Company Information

Hongzhou,ISO9001:2008 certified Hi-tech corporation, is a leading global self-service Kiosk/ATM manufacturer and solutions provider, specializing in researching, designing, manufacturing, and providing complete solution for self service Kiosks.



♦ We have a strong self-service terminal product’s development, software support and system integration capability, and offer customized solution according to client’s individual need.



♦ Equipped with a series of leading precision sheet metal and CNC machine tool equipment, and modern self- service terminal electronic assembly lines, our product are approved by CE, FDA,ROHS, FCC,CCC,IP65 etc.



♦ Our self-service terminal product and solution are designed and manufactured base on lean thinking, with vertical integrated batch production capacity, low-cost structure, and outstanding customer collaboration, we are good at quick response to customer's tailor-made requirement, providing customer with one-stop self- service terminal solution.



♦ Hongzhou high quality product and self-service terminal solution are popular both in the domestic and global markets in over 90 countries, cover financial self-service kiosk, payment kiosk, retail ordering kiosk,ticketing /card issuing kiosk, multi-media terminals, ATM/ADM/CDM, they are widely used in bank, and securities, traffic, shopping mall,hotel,retail, communications, medicine, cinema.

Product Description



Specification of Payment Kiosk
No.ComponentsSpecification
1Computer PartsPC host
(can be customized)

Mainboard: Industrial motherboard,CPU: Intel 1037U

RAM: DDR3 1333 4GB; Hard Disk: 500GB, 7200R

RS-232 Ports, RJ45 interface, 2 cooling fan

4 USB Ports, 10/100M Net Port,Greatwall power supply, cooling fans

Data Cable; Power Cable; Newtwork Cable

Integrated display card, Net Card, SoundCard

2Monitor19.1 inchNew Grade A+ TFT LCD, 16: 9
Brightness: 500cd/m2

Contrast: 10000:1

Lifelong: more than 50 000 hours

Max(native). Resolution: 1280x1024
Response Time: 8ms;VGA interface
3Touch Panel19.1''infrared

Durability: Scratch-free, more than 60,000,000 touches without failure

anti-dust, anti-vandal

Thickness: 3mm; Resolution: 4096×4096; Light Transmit: 95%

Surface Hardness:Mohs' hardness rating of 7

Response Time: 5ms; Interface: USB
4Enclosure

Durable 1.5mm cold rolled steel frame, powder coated steel

Ergonomically sleek and smart design
Easy to install and operate with drawers
Internal fans for ventilation

Left and right bi-channel; amplified output; Multimedia speaker

Moistureproof, Antirust, Anti-acid, Static free

5Special device for Payment kioskBill Acceptor

ITL NV09 banknote acceptor, 600 notes(Max)to hold.

Printer

Thermal printer, 80mm width paper to printer, with auto cutter

6Operating System Not including licensed operating system
7Production Time

15~20 working days after deposite confirmed

8Packing Safty Wooden case for exporting
9Warranty and MOQ

1 Year, aftersale online service forever. MOQ: 1 piece

10Payment Terms

50% Deposit, 50% balance T/T before shipment.

Production Flow

Packaging & Shipping

Payment

Team

FAQ

Q1: Are you manufacturer?
A1: Yes, we're manufacturer and OEM & ODM is accepted.
Q2: What's your MOQ?
A2: One sample is available.
Q3: What's the lead time?
A3: 7~45 days
Q4: What's your guarantee for the kiosk?
A4: 1 year guarantee from the shipping date.
Q5: What is your payment methods ?
A5: T/T, L/C, Western Union, Credit Card, MoneyGram,etc.
Q6: What is transportation way?
A6: By sea,by air, by courier
Q7: What is your trading terms?
A7: EXW, FOB,CIF is our common trading terms

The product is able to bring out a woman's natural existing beauty, while not posing any potential impact on health. Reliable and tested components are seamlessly integrated and placed for optimal serviceability. People will find that the product nearly needs no maintenance, which helps them save much on labor as well as maintenance costs. Reliable and tested components are seamlessly integrated and placed for optimal serviceability.
