Product information
| No. | Components | Brand / Model | Main Specifications | |
| 1 | Industrial PC System | Industrial PC | Mother Board | Intel H81; Integrated Network card and Graphic card |
| CPU | Intel G3250 | |||
| RAM | 4GB | |||
| HDD | 1000G | |||
| Interface | 14*USB; 12*COM; 1*HDMI; 1*VGA; 2*LAN; 1*PS/2; 1*DVI; | |||
| PC Power Supply | HUNTKEY | |||
| 2 | Operation System | Windows 7 （without license） | ||
| 3 | Display+Touch screen | 27" | Screen Size | 27 inch |
| Pixel Number | 1920*1080 | |||
| Brightness | 300cd/m2 | |||
| Contrast | 1000∶1 | |||
| Display Colors | 16.7M | |||
| Viewing Angle | 89°/89°/85°/85° | |||
| Touch point number | 10 point | |||
| Input mode | Finger or capacitor pen | |||
| Surface hardness | ≥6H | |||
| 4 | Cash Accepter | SC Advance | Cashbox box capacity | 1200 notes |
| Note Dimensions | Width: 60 - 83 mm Length: 120 - 177 mm | |||
| Note Acceptance Speed | 2.3 seconds | |||
| Acceptance Rate | 98% or higher | |||
| 5 | Cash dispenser | MMR050 | Note | use the change function |
| Speed | 5 sheets/sec | |||
| Number of box | 4 box | |||
| Banknote box capacity | 3000 sheets for each box | |||
| Maximum number of transactions | 50 sheets | |||
| 6 | Coin dispenser | MK4*2 | Coin dimensions | diameter 16–31mm (0.63”–1.22”) |
| Thickness 1.00–3.50mm (0.039” –0.138”) | ||||
| Coin Capacity | 1,120 x 1, 950 x £1, 1,600 x US 25¢ | |||
| Coin Payout Rate | Three coins per second | |||
| Voltage | 24V | |||
| 7 | Printer | MT532 | Printer Method | Thermal printing |
| Print width | 80mm | |||
| Speed | 250mm/sec(Max) | |||
| Resolution | 203dpi | |||
| Print length | 100KM | |||
| Autocutter | included | |||
| 8 | Camera | ZHB3-A4 | Sensor type | 1/2.7"CMOS |
| Array size | 1928*1088 | |||
| Pixel | 3.0um*3.0um | |||
| Maximum image transfer rate | 1080P 30FPS | |||
| AGC/AEC/Whiter balance | Auto | |||
| 9 | Camera for cash acceptor and dispenser | HDE3120CHP4 | CCD | 1/3" SONY CCD |
| 700TV | ||||
| 10 | Power Supply | LRS-150-24 | AC input voltage range | 100‐240VAC |
| DC output voltage | 24V | |||
| LRS-150-24 | Output over current protection | 110~130% | ||
| LRS-150-12 | Operating temp. & humidity | ‐10~+50,20%~90%RH (noncondensing) | ||
| LRS-150-12 | AC input voltage range | 100‐240VAC | ||
| DC output voltage | 12V | |||
| 11 | LED lamp control module | HY-LED01 | Provide 8-way 5V dual-color lamp output 4-way 12V output | |
| 12 | Speaker | kinter | Dual channel amplified speakers for Stereo , 8Ω 5W. | |
| 13 | KIOSK Cabinet | Hongzhou | Dimention | decided when finish production |
| Color | Optional by customer | |||
| 1. The material of outer metal cabinet is durable 1.5mm thickness cold-roll steel frame; | ||||
| 2. The design is elegant and easy to install and operate; Moistureproof,Antirust, Anti-acid, Anti-dust,Static free; | ||||
| 2.Color and LOGO are upon customers' requests. | ||||
| 14 | Accessories | Security Loc ,2 ventilation fans, Wire-Lan Port; Power sockets for electricity, USB ports;Cables, Screws, etc. | ||
| 15 | Assembling and testing | |||
| 16 | Packing | Security Packing Method with Bubble Foam and Wooden Case | ||
Product features
※ Innovative & smart design, elegant looking, anti-corrosion power coating;
※ Ergonomically and compact structure, user friendly, easy for maintenance;
※ Anti-vandalism, dust-proof, high safety performance;
※ Rugged steel frame and overtime running, high precision, high stability & reliability;
※ Cost-effective, customer-oriented design, the applicable environmental.
Product details
1.Q:Are you a factory or trading company?
A:We are a OEM/ODM factory
2.Q:Where is your factory located? How can I visit there?
A:Our factory is located in A Building 2 floor,Ground pine eco-technology Park,Jie Bao Road 9,shiyan town,street community in paddy field,Bao an District,Shenzhen,China.
3.Q:Can I get some sample?
A:Sample order is welcome.
Price would be negotiated bassed on bigger quantity
4.Q:How does your factory do regarding quality control?
A:Our company's philosophy is: customer first, quality is the life, integrity management, innovation is the company's blood.We have very excellent product designers and engineers for quality escort and provide 24-hour after-sales service.Our factory has gained CE/CCC/FCC/ROHS/IP65&IP66.And welcome to visit our factory.
5.Q:What is your after-sale service?
A:We offer 100% guarantee on our product.
6.Q:When will you make the delivery?
A:We can make the delivery within 3-15 working days according to the size of your order.
If you want to know more about our products and company,welcome to contact us any time.
| LCD Panel | Type of Display | TFT-LCD |
Panel Size | 15, 17, 19 inch | |
Display Ratio | 4:3 or 16:9 | |
| Response Time | 5ms | |
| Windows OS | CPU | Intel® i3-3220 |
Graphics | Intel HD Graphic 2500 | |
| RAM | DDR3, 4GB | |
| HDD | 500GB | |
| WIFI | WIFI module+WIFI Antenna | |
| Touchtech | Option 1 | Infrared 6 touch points |
| Option 2 | Capacitive 10 touch points | |
| Main components
| Card Reader | Card Type: Magcard, IC Card, RF Card, Mifare Card, UL Card |
Interface: RS232/USB | ||
Card Entry Method: Signal of Magnetic, Optoelectronic and rear card | ||
Encrypted Pin Pad | Key Life Span: 2,000,000 cycles | |
Key Force: 2-3N | ||
Key Trip: >2.5mm | ||
Protection Level: IP65 | ||
Bill Acceptor | Brand: Cash Code/ MEI/ ITL/ICT | |
Validation Rate: High than 96% | ||
Capacity: 600notes~1500notes | ||
Thermal Printer | Auto-cutter: Included | |
Width of Paper: 50mm/80mm/112mm | ||
Printing Speed: 150mm/s | ||
Buffer of Data: 4Kb | ||
Interface: RS232/USB | ||
| Optional component | A4 Printer, Coin acceptor, UPS, Web-camera etc | |
| Main Hardware | Shell Material | Tempered glass+4.5 mm thickness Metal Back Shell |
| Suface |
Metal case with powder burning;Tempered glass to protect LCD panel | |
| Speaker |
2*10W built-in stereo speakers | |
Heat Dispersion | Built-in DC fans | |
| Power | Standby | ≤3W |
Working | 30W-180W | |
| Power supply | AC 110V - 240V, 50/60HZ | |
| Storage Temperature | -7℃ to 65℃ | |
| Normal Working Temperature | -5℃ to 65℃ |
