Components | Brand / Model | Main Specifications | |||
Industrial PC System | Industrial PC | Mother Board | Intel H81; Integrated Network card and Graphic card | ||
CPU | Intel i5 6200U | ||||
RAM | 8GB DDR4 | ||||
SSD | 120G | ||||
Interface | 10*USB, 6*COM, 1*SATA,1*HDMI; 1*VGA; 2*LAN; 1*AUDIO | ||||
PC Power Supply | HUNTKEY 300W | ||||
Operation System | Windows 7(without license) | ||||
Touch screen | 46" | Screen Size | 46 inch | ||
Pixel Number | 1920*1080 | ||||
Pixel pitch | 250cd/m2 | ||||
Contrast | 1000∶1 | ||||
Display Colors | 16.7M | ||||
Viewing Angle | 89°/89°/89°/89° | ||||
LED Life Time | Min. 30000hrs | ||||
Touch technology | IR | ||||
Surface hardness | ≥6H | ||||
Card Reader | IM500 | Card Readers | Triple track MSR / EMV L1 & L2 certified | ||
Ingress protection | IP34 | ||||
Certications | PCI PTS 5.x, SRED I EMV L1 & L2, MasterCard TQM I UL I CE FCC I RoHs ,EMV L1 & L2 | ||||
PINpad | IM310 | Keypad | 16 Keys | ||
Ingress protection | IP65 | ||||
Certications | PCI PTS 5.x, SRED I EMV L1 & L2,MasterCard TQM I UL I CE FCC I RoHs | ||||
Printer | KM216H | Printer Method | Thermal printing | ||
Print width | 216mm | ||||
Speed | 180mm/sec(Max) | ||||
Resolution | 203dpi | ||||
Print length | 100KM | ||||
Autocutter | included | ||||
Barcode Scanner | 7160 | Image (Pixels) | 640 pixels(H) x 480 pixel(V) | ||
Light Source | Illumination: 6500K LED | ||||
Field of View | 80°(H) x 64° (V) | ||||
Interfaces Supported | USB | ||||
1-D | UPC, EAN, Code128, Code 39, Code 93, Code11, Matrix 2 of 5, Interleaved 2 of 5, Codabar, MSI Plessey, GS1 DataBar, China Postal, Korean Postal, etc. | ||||
2-D | PDF417, MicroPDF417, Data Matrix, Maxicode, QR Code, MicroQR, Aztec, Hanxin, etc. | ||||
Document Scanner | Q800L | Document size | A4, A3 | ||
Pixels | 8 million (3264*2448) | ||||
Output format | YUV, MJPG | ||||
Amount of distortion | <1% | ||||
Whiter balance | Auto | ||||
Camera | ZHB3-A4 *2 | Sensor type | 1/2.7"CMOS | ||
Array size | 1928*1088 | ||||
Pixel | 3.0um*3.0um | ||||
Maximum image transfer rate | 1080P 30FPS | ||||
AGC/AEC/Whiter balance | Auto | ||||
Printer 80mm | Epson-MT532 | Printer Method | Thermal printing | ||
Print width | 80mm | ||||
Speed | 250mm/sec(Max) | ||||
Resolution | 203dpi | ||||
Print length | 100KM | ||||
Autocutter | included | ||||
Finger printer | ZT-998AFB-V51 | Fingerprint sensor type | capacitive | ||
Entry time | <1S | ||||
Fingerprint authentication: | support for fingerprint verification (1:1) and fingerprint search (1:N) | ||||
Interface | USB | ||||
Telephone | AFT-HS-02T | ||||
Power Supply | LRS-150-24 | AC input voltage range | 100‐240VAC | ||
DC output voltage | 24V | ||||
LRS-150-12 | AC input voltage range | 100‐240VAC | |||
DC output voltage | 12V | ||||
LED Indicator | LED indicator for document scanner | ||||
Speaker | kinter | Dual channel amplified speakers for Stereo , 8Ω 5W. | |||
KIOSK Cabinet | Hongzhou | Dimention | decided when finish production | ||
Color | Optional by customer | ||||
1. The material of outer metal cabinet is durable 1.5mm thickness cold-roll steel frame; | |||||
2. The design is elegant and easy to install and operate; Moistureproof,Antirust, Anti-acid, Anti-dust,Static free; | |||||
2.Color and LOGO are upon customers' requests. | |||||
Accessories | Security Loc ,2 ventilation fans, Wire-Lan Port; Power sockets for electricity, USB ports;Cables, Screws, etc. | ||||
Assembling and testing | |||||
Packing | Security Packing Method with Bubble Foam and Wooden Case | ||||
Other Optional hardware components List of the payment kiosk is as following:
