| lcd kiosk: | Touch screen Technology |
| Display area(mm)/mode: | 1428.48(W)×803.52mm(H) 16:9 |
| Maximum resolution: | 1920*1080 FHD |
| Display color: | 16.7M |
| Pixel Pitch(mm): | 0.744(H)×0.744mm(V) |
| Brightness (nits): | 500nits |
| Contrast: | 4000:01:00 |
| Visual angle: | 178°/178° |
| Response: | 6.5ms |
| Touch screen: | CVT infrared two-point touch screen |
| PC Specification: | mini PC |
| Main board: | H61 |
| CPU: | Intel 32 core I3, dual-core ,3.10GHz |
| RAM: | DDR3, 4GB |
| HDD: | 500G |
| Graphics: | IntelHD2000 (CPU integrated) |
| Wifi model: | Yes |
| Wired network: | built-in Realtek RTL8103EL |
| LED panel: | Original factory Grade A new panel |
| Panel life: | above 50,000hrs |
| Operating System: | Windows 7, Windows 8, Windows XP etc. |
The above PC configuration is for your reference, i5, i7 series and other configurations are also available to meet your standards,please inform us if needed. | |
| Physical Specification: | |
| Kiosk shell material: | 1.5mm cold rolled steel+Acrylic cover/ anti-scratched tempered glass |
| Color: | Black/White/customized colors |
| Fan: | 2X12V fans |
| Audio/Speakers: | 2 x 8Ω10W Speakers, 1 x 30W Amplifier |
| Ports/Slots: | Power input | Power switch | PC switch | USB | LAN |
| Cables: | Standard international power cable |
| or according to your requirement | |
| Power supply: | AC 110–240, 50-60Hz |
| Operating temperature: | 0°C ~ +40°C |
| Storage temperature: | -20°C ~ +60°C |
| Humidity: | 0% ~ 80% |
| Other Kiosk Components: | all are optional, please inform us if needed. |
| Camera: | Logitech |
| Wired network: | 3G/GPRS modem, Bluetooth, GPS receiver |
| Printers: | 58mm,80mm, ticket printers |
| Input: | Keyboards, Touch pads, Trackballs |
| Card Devices: | Magnetic / IC / RFID devices, Multi-card reader |
| Payment Devices: | Debit / Credit Card Payment devices, Bill & Coin devices |
| Scanners: | Barcode & document scanners |
| Authentication: | Biometric devices & signature pads |
Trade Info.
1.Trade terms >>FOB,CIF,EXW
2.Payment terms >>TT,Western Union,PayPal,Escrow,MoneyGram
3.Payment condition >>50% deposit in advance,50% balance before delivery
4.Delivery time >>5-7days after deposit,3~4 working days for inventory
5.Packing >>Neutral carton,wooden case for large size
6.Shipping >>By sea,by air and by express
Trade Procedure
Inquiry >>Reply >>Contract >>Receive payment >>Produce >>Testing&packing >>Delivery >>Receiving
After-Sale Service
1.Supply OEM&ODM Service,independent QC department,many times testing and checking well in site
2.100% QC pass checking and testing before shipping
3.13 months of warranty
4.CE,RoHs,FCC
Hongzhou, ISO9001:2008 certified Hi-tech corporation, is a leading global self-service Kiosk/ATM manufacturer and solutions provider, specializing in researching, designing, manufacturing, and providing a complete solution for self service Kiosks.
We have a strong self-service terminal product’s development, software support and system integration capability, and offer customized solution according to client’s individual need.
Equipped with a series of leading precision sheet metal and CNC machine tool equipment, and modern self-service terminal electronic assembly lines, our product are approved by CE, FDA,ROHS, FCC,CCC,IP65 etc.
Our self-service terminal product and solution are designed and manufactured base on lean thinking, with vertical integrated batch production capacity, low-cost structure, and outstanding customer collaboration, we are good at quick response to customer's tailor-made requirement, providing customer with one-stop self-service terminal solution.
Hongzhou high quality product and self-service terminal solution are popular both in the domestic and global markets in over 90 countries, cover financial self-service kiosk, payment kiosk, retail ordering kiosk, ticketing/card issuing kiosk, multi-media terminals, ATM/ADM/CDM, they are widely used in bank, and securities, traffic, hotel, retail, communications, medicine, cinema.
Q1: Are you manufacturer?
A1: Yes, we're manufacturer and OEM & ODM is accepted.
Q2: What's your MOQ?
A2: One sample is available.
Q3: What's the lead time?
A3: 7~45 days
Q4: What's your guarantee for the kiosk?
A4: 1 year guarantee from the shipping date.
Q5: What is your payment methods ?
A5: T/T, L/C, Western Union, Credit Card, MoneyGram,etc.
Q6: What is transportation way?
A6: By sea,by air, by courier
Q7: What is your trading terms?
A7: EXW, FOB,CIF is our common trading terms
