Industrial PC System | Mother Board | Intel H81; Integrated Network card and Graphic card | |
CPU | Intel i3 4170 | ||
RAM | 4GB | ||
SSD | 120G | ||
Interface | 14*USB; 12*COM; 1*HDMI; 1*VGA; 2*LAN; 1*PS/2; 1*DVI; | ||
PC Power Supply | HUNTKEY 300W | ||
Operation System | Windows 7/10(without license) | ||
Display+Touch screen | Screen Size | 19 inch | |
Pixel Number | 1280*1024 | ||
Pixel pitch | 250cd/m² | ||
Contrast | 1000∶1 | ||
Display Colors | 16.7M | ||
Viewing Angle | 85°/85°/80°/80° | ||
LED Life Time | Min. 30000hrs | ||
Touch point number | 10 point | ||
Input mode | Finger or capacitor pen | ||
Surface hardness | ≥6H | ||
Advertising Display | Screen Size | 19 inch | |
Pixel Number | 1280*1024 | ||
Brightness | 250cd/m² | ||
Contrast | 1000∶1 | ||
Display Colors | 16.7M | ||
Viewing Angle | 85°/85°/85°/85° | ||
LED Life Time | Min. 30000hrs | ||
Card dispenser | Support card type | Mifare 1,RF card ,ISO1443A,ISO15693 read and write and dispensed | |
Card size | L:85±0.5mm，W:54±0.5mm，T:07～1.0MM | ||
Card recycling | Yes | ||
Card box capacity | 200 pcs (card thickness based on 0.76mm ) | ||
Card volume alarm: | less 10 pcs | ||
A4 Size printer | Printer Method | Laser printer | |
Resolution | 600*600dpi | ||
Print speed | 38 pages per minute | ||
page box | 250 pages | ||
Power | AC 220-240V(±10％)，50/60Hz(±2Hz),2A | ||
Printer | Printer Method | Thermal printing | |
Print width | 80mm | ||
Speed | 250mm/sec(Max) | ||
Resolution | 203dpi | ||
Print length | 100KM | ||
Autocutter | included | ||
Passport/Idcard/driving licence Reader | Imaging | Window Size: 127*96 mm Sensor: CMOS 3Megapixel (2048*1536) Resolution: 400 DPI | |
OCR processing | Passport, ID card, driving licence ICAO Doc 9303 Compliance (Part1-4) OCR processing: ≤1s | ||
Trigger | Auto-trigger, and Auto-detected/classified travel document type | ||
Cash acceptor and dispenser | Cash size | Accepts:Width: 60 - 85 mm,Length: 115 - 170 mm | |
Recycles:Width: 60 - 82 mm | |||
Cash box capacity | 1000 notes | ||
Recycler Capacity | Up to 70 mixed notes | ||
Protocols | SSP ccTalk | ||
MCBF | 100,000 | ||
Metal Keyboard | Panel | 65 keys stainless steel panel mounting keyboard with trackball | |
Certification | CE, FCC, RoHS, ESD compliant | ||
Protection level | Waterproof and Dustproof class: IP65 (front panel),Vandal resistant class: IK07 | ||
Lifespan | >2 million operations per key | ||
QR code scaner | Image (Pixels) | 640 pixels(H) x 480 pixel(V) | |
Light Source | Illumination: 6500K LED | ||
Field of View | 72°(H) x 64° (V) | ||
Minimum Resolution: | ≥3.9 mil | ||
1-D | UPC, EAN, Code 128, Code 39, Code 93, Code 11, Matrix 2 of 5, Codabar Interleaved 2 of 5, Mis Plessey, GSI DataBar, China Postal, Korean Postal , etc | ||
2-D | PDF417, MicroPDF417, Data Matrix, Maxicode, QR Code, MicroQR, Aztec Hanxin, etc. | ||
Camera | Sensor type | 1/2.7"CMOS | |
Array size | 1928*1088 | ||
Pixel | 3.0um*3.0um | ||
Maximum image transfer rate | 1080P 30FPS | ||
AGC/AEC/Whiter balance | Auto | ||
Microphone and Speaker, Handset Phone | Dual channel amplified speakers for Stereo , 8Ω 5W. | ||
Swipe Card Reader | Provided by customer | ||
LCD signature pad | |||
Wifi and Bluetooth Connectivity | |||
UPS | Input:220V, 1000VA,600W, Autonomy: 20 minutes | ||
Power Supply | AC input voltage range | 100‐240VAC | |
DC output voltage | 24V | ||
AC input voltage range | 100‐240VAC | ||
DC output voltage | 12V | ||
KIOSK Cabinet | Dimention | decided when finish production | |
Color | Optional by customer | ||
1. The material of outer metal cabinet is durable 1.5mm thickness cold-roll steel frame; | |||
2. The design is elegant and easy to install and operate; Moistureproof,Antirust, Anti-acid, Anti-dust,Static free; | |||
3.Color and LOGO are upon customers' requests. | |||
Accessories | Security Loc ,2 ventilation fans, Wire-Lan Port; Power sockets for electricity, USB ports;Cables, Screws, etc. | ||
Assembling and testing | |||
Packing | Security Packing Method with Bubble Foam and Wooden Case | ||
Other Optional hardware components List of the payment kiosk is as following:
