| Components List | ||||
| No.1 | Components | Brand / Model | Main Specifications | |
| 1 | Industrial PC System | Industrial PC | Mother Board | Baytrail; Integrated Network card and Graphic card |
| CPU | Intel J1900 | |||
| RAM | 4GB | |||
| HDD | 1000G | |||
| Interface | 8*USB, 6*COM, 1*VGA, 2*LAN,1*AUDIO, 1*LPT, 1*PS/2 | |||
| PC Power Supply | LRS-75-24 | |||
| 2 | Operation System | Windows7(without license) | ||
| 3 | Display | Auo | Screen Size | 19 inch |
| Pixel Number | 1280*1024 | |||
| Brightness | 350cd/m2 | |||
| Contrast | 1000∶1 | |||
| Display Colors | 16.7M | |||
| Viewing Angle | 85°/85°/80°/80° | |||
| LED Life Time | Min. 40000hrs | |||
| 4 | Touch Screen | EG | Screen Diagonal | 19 inch |
| Touch technology | Capacitive | |||
| Touch Points | Multi-finger | |||
| Glass Hardness | 6H | |||
| Min.Reprot Rate | 100points/sec | |||
| Operation Conditions | -40°C~+85°C at Min 20% to Max 90%RH | |||
| 5 | Non-contact card reader | RS102 | Name | Double frequency card reader |
| Dimension | 104mm*68mm*10mm | |||
| Support | ID: EM4100,4200,TK4100and compatible card IC: Mifare one s50/S70,etc | |||
| Frequency | 125KHz,13.56MHz | |||
| Reader time | <0.5s | |||
| Consumed Current | 70mA | |||
| Operating Distance | 0~10cm | |||
| Interface | USB | |||
| Status Indication | 1pc LED | |||
| 6 | Code keyboard | KMY3501B | Mechanical property | Keyboard life: >2000000 times per key |
| physical property | 4 x 4 keyboard design (10 numeric keys, 6 function keys) | |||
| Safety characteristics | Inside the keyboard's security module, the PIN is encrypted | |||
| Function description | Support DES and TDES encryption and decryption algorithm, PIN encryption, MAC computing | |||
| 7 | Two-dimensional code scan | 7160 | Image (Pixels) | 640 pixels(H) x 480 pixel(V) |
| Light Source | Illumination: 6500K LED | |||
| Field of View | 80°(H) x 64° (V) | |||
| Print Contrast£º | 20% minimum reflective difference | |||
| Interfaces Supported£º | USB , RS232 | |||
| 1-D | UPC, EAN, Code128, Code 39, Code 93, Code11, Matrix 2 of 5, Interleaved 2 of 5, Codabar, MSI Plessey, GS1 DataBar, China Postal, Korean Postal, etc. | |||
| 2-D | PDF417, MicroPDF417, Data Matrix, Maxicode, QR Code, MicroQR, Aztec, Hanxin, etc. | |||
| 8 | Printer | Epson-MT532 | Printer Method | Thermal printing |
| Print width | 80mm | |||
| Speed | 250mm/sec(Max) | |||
| Resolution | 203dpi | |||
| Print length | 100KM | |||
| Autocutter | included | |||
| 9 | Camera | C270 | Photosensitive element | CMOS camera |
| pixel | 5 million | |||
| Built-in microphone | yes | |||
| Maximum frame number | 30 frames / second frame | |||
| 10 | Power Supply | RD-125-1224 | AC input voltage range | 100‐240VAC |
| Frequency | 50Hz to 60Hz | |||
| Output over current protection | 110~130% | |||
| Operating temp. & humidity | ‐10~+50,20%~90%RH (noncondensing) | |||
| 11 | Speaker | Kinter | Dual channel amplified speakers for Stereo , 8Ω 5W. | |
| 12 | KIOSK Cabinet | Hongzhou | Dimention | decided when finish production |
| Color | Optional by customer | |||
| 1. The material of outer metal cabinet is durable 1.5mm thickness cold-roll steel frame; | ||||
| 2. The design is elegant and easy to install and operate; Moistureproof,Antirust, Anti-acid, Anti-dust,Static free; | ||||
| 2.Color and LOGO are upon customers' requests. | ||||
| 13 | Accessories | Security Lock for anti theft , tray for easy maintenance,2 ventilation fans, Wire-Lan Port; Power sockets for electricity, USB ports;Cables, Screws, etc. | ||
| 14 | Packing | Security Packing Method with Bubble Foam and Wooden Case | ||
Product features
※ Innovative & smart design, elegant looking, anti-corrosion power coating
※ Ergonomically and compact structure, user friendly, easy for maintenance
※ Anti-vandalism, dust-proof, high safety performance
※ Rugged steel frame and overtime running, high precision, high stability & reliability
※ Cost-effective, customer-oriented design, the applicable environmental
※ Payment kiosk with Visa card reader
Product details
Are you a manufacturer or trading company ?
We are a manufacturer with own factory and OEM service could be accept.
What's your after-sale service ?
The warranty of our products is 1 year, during this time if the machine brokens we could fix it back and around, but the freight is covered by you, if the parts lost, we can sent it by express.
How about the sample ordered ?
Customers can order a sample before bulk orders to check the quality as required.
What's your panel provider ?
Our panel is original LG.
