Company Advantages1. payment machine kiosk is a result of Chinese workmanship – from design engineering through to fabrication. Its production only relies on highly qualified staff and on state-of-the-art facilities.
2. The product is quality-assured as we have established a good quality management system to prevent any possible defects.
3. Any defect of the product has been avoided or eliminated during our strict quality assurance procedure.
4. This product contributes to life convenience. People will find it beneficial because it offers a solution to get to know the world.
5. The product is not subject to overheating which may burn fingers. People who used it for several years have admitted that it is cool to touch whenever because it generates very little heat.
Components List |
No. | Components | Brand / Model | Main Specifications |
1 | Industrial PC System | Industrial PC | Mother Board | Baytrail Integrated Network card and Graphic card |
CPU | Intel J1900 |
RAM | 4GB |
HDD | 1000G |
Interface | 8x USB, 6 x COM, 1 x VGA, 2x LAN,1x AUDIO, 1x LPT, 1*PS/2 |
PC Power Supply | llano(12V5A) |
2 | Operation System |
| Windows 7(without license) |
3 | Display | Auo | Screen Size | 10.1 inch |
Pixel Number | 1366X768 |
Brightness | 350cd/m2 |
Contrast | 900:1 |
Display Colors | 16.7M |
Viewing Angle | 80/80/85/85 (up / down / left / right) |
LED Life Time | Min. 40000hrs |
4 | Touch Screen | EG10.1 | Screen Diagonal | 10.1 inch |
Touch technology | Capacitive |
Touch Points | Multi-finger |
Glass Hardness | 6H |
Min.Reprot Rate | 100points/sec |
Operation Conditions | -40°C~+85°C at Min 20% to Max 90%RH |
5 | Printer | Epson-MT532 | Printer Method | Thermal printing |
Print width | 80mm |
Speed | 250mm/sec(Max) |
Resolution | 203dpi |
Print length | 100KM |
Autocutter | included |
6 | Cash accepter | NV9 | Mean fault free | More than 800 thousand cycles |
Currency reading speed | Less than 3.0 seconds |
The box capacity | Less than 600 |
Recognition rate | Acceptance rates can be as high as 99.8% |
Characteristic | According to the different panel width there are three panel options, 66mm, 69 mm, 82 mm |
|
The same kind of paper money to support multiple countries of the currency, you can freely download from our website |
7 | Modem | TPLINK | receipt wifi signal |
8 | Speaker | OP‐100 | Dual channel amplified speakers for Stereo , 8Ω 5W. |
9 | KIOSK Cabinet | Hongzhou | Dimention | decided when finish production |
Color | Optional by customer |
1. The material of outer metal cabinet is durable 1.5mm thickness cold-roll steel frame; |
2. The design is elegant and easy to install and operate; Moistureproof,Antirust, Anti-acid, Anti-dust,Static free; |
2.Color and LOGO are upon customers' requests. |
10 | Accessories | Security Lock for anti theft , tray for easy maintenance,2 ventilation fans, Wire-Lan Port; Power sockets for electricity, USB ports;Cables, Screws, etc. |
|
11 | Packing | Security Packing Method with Bubble Foam and Wooden Case |
|
※ Innovative & smart design, elegant looking, anti-corrosion power coating
※ Ergonomically and compact structure, user friendly, easy for maintenance
※ Anti-vandalism, dust-proof, high safety performance
※ Rugged steel frame and overtime running, high precision, high stability & reliability
※ Cost-effective, customer-oriented design, the applicable environmental
※ Bank card reader and 10.1 inch touch screen
Company Features1. The industrial output value and export value of Hongzhou Smart Tech Co.,Ltd have increased year by year.
2. We have an excellent customer service team. They have deep customer insight. They understand how to help clients make the right choice, what clients actually need, and how to get closer to customers.
3. Improving customers' satisfaction is always our objective. We believe that customer satisfaction is critical in helping our company develop into a more well-known enterprise. Inquire now! In addition to the self service payment kiosk manufacturer improvements, we will continue to improve our services. Inquire now! We strive for long-term success through sustainable development. We closely work together with the local communities and government to minimize the impact on the environment during our production. We manage the environmental impact of our activities with a sense of responsibility. Our staff is required to identify and apply the necessary improvements and development activities that minimize or eliminate negative environmental impact.
