| Components List | ||||
| No. | Components | Brand / Model | Main Specifications | |
| 1 | Industrial PC System | Industrial PC | Mother Board | Advantech 683 G2 |
| CPU | I3 4130 | |||
| RAM | 8GB | |||
| HDD | 120G | |||
| Interface | 14*USB; 12*COM; 1*HDMI; 1*VGA; 2*LAN; 1*PS/2; 1*DVI; | |||
| PC Power Supply | ATX power supply | |||
| 2 | Operation System | Windows 7(without license) | ||
| 3 | Display | 19" | Screen Size | 19 inch |
| Pixel data | 1280x1024 | |||
| Brightness | 350cd/m2 | |||
| Contrast | 1000∶1 | |||
| Display Color | 16.7M | |||
| Angle | 85°/85°/80°/80° | |||
| Lifetime | Min. 40000hrs | |||
| 4 | Touch Screen | 19" | Screen Size | 19 inch |
| Touch technology | capacitance | |||
| First catch | Multi-finger | |||
| Hardness | 6H | |||
| Min.Reprot | 100points /second | |||
| Oscillation frequency | 12MHz | |||
| 5 | Advertising screen | 21.5" | Screen size | 21.5 inch（(with tempered glass panel)） |
| Pixel | 1920*1080 | |||
| Brightness | 250cd/m2 | |||
| Contrast | 3000∶1 | |||
| Display Colors | 16.7M | |||
| Lifetime | Min. 40000hrs | |||
| 6 | A4/A5 printer | HP 1020 | Printer mode | A4 laser printer |
| Printing speed | 14PPM | |||
| Monthly print load | 5000 sheet | |||
| Resolution ratio | 600*600dpi | |||
| Paper in box | 150 sheet | |||
| 7 | Second ID card reader | IDM-10 | Standard specification | ISO/IEC 14443 TYPE B standard，include GA 450-2013 ID card reader |
| Read card response rate | <1S | |||
| Reading distance | 0-30mm | |||
| Working | 13.56MHz | |||
| Interface | USB , RS232 | |||
| 8 | Timing switch | HY-DS01 | Function | Support one key shutdown, timing switch machine, remote switch machine control function. |
| 9 | Qr code scanning | XN-202 | Recognition mode | COMS |
| Resolution ratio | 300 000 | |||
| Read code system 1D | UPC/EAN with supplementals,Bookland EAN,ISSN,UCC Coupon Extended Code,Code 128,GS1-128,ISBT 128,Code 39,Code 39 Full ASCII,Trioptic Code 39,Code 32,Code 93,Code 11,Matrix 2 of 5,interleaved 2 of 5,Discrete 2 of 5,Codabar,MSI,Chinese 2 of 5,GSI DataBar Variants,Korean 3 of 5,ISBT Concat etc. | |||
| Read code system 2D | PDF417,MicroPDF417,Composite Codes,TLC-39,Data Matrix,Maxicode,QR code,MicroQR,Azt etc. | |||
| Light sourc | LED (630nm ± 10nm) | |||
| 10 | Switch | LRS-75-24 | Input voltage | 100‐240VAC |
| Output voltage | 24V | |||
| LRS-150-12 | Input voltage | 100‐240VAC | ||
| output voltage | 12V | |||
| 11 | Speaker | kinter | Dual channel amplifier stereo，8Ω5w. | |
| 12 | Cabinet | HZ | Size | According to actual function and effect diagram, accord with human engineering. |
| Color | In line with the aesthetic requirements, customers can choose that color | |||
| 1. The outer metal cabinet is made of a durable cold-rolled steel frame. | ||||
| 2. The design is beautiful and easy to install and operate;Moisture-proof, rust-proof, dustproof, no static electricity; | ||||
| 3.The logo is based on customer requirements. | ||||
| 13 | Accessory | Anti-theft lock, tray, easy to maintain, 2 fan, line LAN port;Power socket, relay, USB port, cable, screw, etc. | ||
| 14 | Assembly | |||
| 15 | Package | Bubble foam and safe packing method for cartons. | ||
Product features
※ Innovative & smart design, elegant looking, anti-corrosion power coating
※ Ergonomically and compact structure, user friendly, easy for maintenance
※ Anti-vandalism, dust-proof, high safety performance
※ Rugged steel frame and overtime running, high precision, high stability & reliability
※ Cost-effective, customer-oriented design, the applicable environmental
Product details
