Operate System | Windows7 |
Main control module | Intel Core i5 CPU,4G RAM, 500GB HDD, 2 way VGA output, Integrated sound card, Dual network card, 10 x UART,8 X 2.0 USB Port, 4 X 3.0USB Port, HDMI interface,Mics and earphones interface, Audio interface, Parallel Port, 2 x PS2 interface(keyboard and mouse) |
Cash dispenser module | CDM8240; Full condition detection and run out of cash detection, banknote capacity:3000 pieces. Bulk notes dispenser. Cash will be accepted at once. |
Dispensing speed | 7notes/second |
Banknotes Identification module | High-speed banknotes Scanning,recording and store the banknotes reference No. by OCR |
Display | 19”TFT touch screen,Resolution 1280*1024 |
Card reader | PSAM card, IC card and Magcard abide by ISO and EMV ,PBOC 3.0 |
Pin pad shield | Supported |
Customer awareness mirror | Supported |
Receipt Printer | Thermal Printer |
Barcode Scanner | 2D |
Camera | 1080P,Paranomic photography in operation zone |
UPS | Certified by 3C(CCC) |
Power supply | 220V~50Hz 2A |
Temperature | Indoor:0℃ ~ +35℃; |
Relative Humidity | 20%~ 95% |
Other Optional hardware components List of the payment kiosk is as following:
