    PCB PCBA Factory SMT DIP Technology PCBA Assembly

    Product Description

    PCB PCBA Factory SMT DIP Technology PCBA Assembly 7



    PCB Assembly Capability:
    Stencil Size: 736x736mm
    Minimum IC Pitch: 0.2mm
    Maximum PCB size: 1200x 500mm
    Minimum PCB thickness: 0.25mm
    Minimum chip size: 0201 (0.2x0.1)/0603 (0.6 x 0.3mm)
    Maximum BGA size: 74x74mm
    BGA ball pitch: 1.00mm (minimum), 3.00mm (maximum)
    BGA ball diameter: 0.40mm (minimum), 1.00mm (maximum)
    QFP lead pitch: 0.38mm (minimum), 2.54mm (maximum)
    Volume:
    One piece to low volume production quantities
    Low cost first article builds
    Schedule deliveries
    Assembly type: Surface mount(SMT) assembly
    DIP assembly
    Mixed(surface mount and through hole) technology
    Single or double sided placement
    Cable assembly
    Components type: Passive components:
    As small as 0402 package
    As small as 0201 with design review
    Ball Grid Arrays(BGA):
    As small as .5mm pitch
    Parts procurements: Turnkey(we supply the parts)
    Consigned(you supply the parts)
    You supply some parts, we do the rest
    Solder type: Leaded
    Lead-free/ROHS compliant
    Other capabilities: Repair/rework services
    Mechanical assembly
    Box build
    Mold and plastic injection.



    Delivery Time for PCB



    Layer Prototype Mass Productions
    Quick Turn  Unual Time (above 30 m2 )
    2 24 hours 3-4 days 8-10 days
    4 48 hours 5-6 days 10-12 days
    6 72 hours 6-8 days 12-14 days
    8 96 hours 8-10 days 14-16 days
    10 120 hours 12-14 days 16-18 days
    ... ... ... ...



    Delivery Time for PCBA



    Order Conditions Standard Delivery Date The fastest Delivery Date
    Prototype (<20 pcs)   2 days 8 hours
    Small Volum (20-100 pcs)  3 days  12 hours
    Medium Volum(100-1000 pcs)   6 days 24 hours
    Mass productions (>1000 pcs)  Depends on BOM Depends on BOM
    Detailed Images

    PCB PCBA Factory SMT DIP Technology PCBA Assembly 9

    Production Flow

    PCB PCBA Factory SMT DIP Technology PCBA Assembly 11



    Applications

    PCB PCBA Factory SMT DIP Technology PCBA Assembly 13

    Our Services

    1. Who we are

    PCB Manufacturer Flexibility Quality
    Hongzhou, firstly established as a PCB manufacturer, has its own PCB factory with advanced manufacturing facilities, capable in fabricating up to 24 layers PCB boards. The factory is ISO9001 certified, with its PCB products UL approved and RoHS compliant. Your PCB cost and lead time can be reduced to buy PCBs from us. Hongzhou is highly customer oriented catering for customer's specific requirements. There are various kinds of available services, you can choose either full turn-key solutions or any single specific service. We can handle any size project from minimum quantity one piece to mass production. And we provide quick turn PCB and PCBA manufacturing service. Hongzhou fully understands the importance of quality for your projects. The quality control system is integrated in each step from preliminary PCB manufacturing to final PCBA packing, and a well-organized inspection and test procedure is performed to ensure the superior quality. All the products are 100% inspected for each shipment.




    2. Support
    Hongzhou aims to be the leading PCB manufacturer, and provide quality PCB products for electronic industry.

    Layers 1-16 layers Min Board Thickness(2-layer) 0.2mm
    Max Board Size 635 × 1100mm Min Board Thickness(4-layer) 0.6mm
    Min Board Size 20 × 30mm Min Inner-layer Thickness 0.1mm
    Min Trace 0.1mm Min Annular Ring 0.1mm
    Min Space 0.1mm Min Hole Location Tolerance ±0.075mm
    Min Hole Size 0.2mm Min Hole Size Tolerance ±0.05mm
    Board Warp ≤ 1° Min Outer Dimension Tolerance ±0.1mm
    Solder Mask Green, Yellow, Red, Black, Blue, White
    Surface Finish HAL, HASL, Immersion Gold, Immersion Silver, Plating Gold, Plating Nickel, Plating Silver, Gold Finger, OSP
    Board Material FR-4, High Tg FR-4, Halogen Free FR-4, Thick Copper FR-4, Aluminium Based, Rogers, Taconic
    Acceptable file Gerber file(RS-274-X or RS-274-D with aperture list and drill files),Protel,PADS,POWERPCB,AutoCAD,ORCAD
    CAM software Genesis, CAM350



    3. PCB + Assembly
    More and more of our existing PCB customers are now asking us for fully Assembled Printed Circuit Boards delivered to their door to take away all the time consuming stress of component procurement and assembly. In order to meet customers' requirements, Sunthone develops from a PCB manufacturer to a one-stop PCBA service provider, including PCB assembly, components sourcing, stencils, cable assembly and final product assembly and testing.

    Available Services

      PCB Manufacturing

      PCB Assembly

      Components Sourcing

      SMT Stencils

      Cable Assembly

      PCBA Testing

      Final Product Assembly
    Assembly Technologces

     SMT

    THT

     Reflow Soldering

     Wave Soldering

     Hand Soldering

     Repair/Rework

     Mixed Assembly Technologies
    Packaging & Shipping

    PCB PCBA Factory SMT DIP Technology PCBA Assembly 15

    FAQ
    Q1.What is needed for PCB PCBA quotation?
    A: PCB: Quantity, Gerber file and Technic requirements(material,surface finish treatment, copper thickness,board thickness ,...)
    PCBA: PCB information, BOM, (Testing documents...)
    Q2. What file formats do you accept for PCB PCBA production?
    A: Gerber file: CAM350 RS274X
    PCB file: Protel 99SE, P-CAD 2001 PCB
    BOM: Excel (PDF,word,txt)
    Q3. Are my files safe?
    A: Your files are held in complete safety and security.We protect the intellectual property for our customers in the whole process.. All documents from customers are never shared with any third parties.
    Q4. MOQ?
    A: There is no MOQ in POE.We are able to handle Small as well as large volume production with flexibility.
    Q5.Shipping cost?
    A: The shipping cost is determined by the destination, weight, packing size of the goods. Please let us know if you need us to quote you the shipping cost.
    Q6. What service do you have?
    A: We mainly focus on PCB+Assembly+Components sourcing service. Additionally, we can also provide programming, testing, cables, enclosure assembly service.



    Any inquiry about PCB Assembly for OEM service,please feel free to contact me.Thanks!
