PCBA Factory Electronic Printed Circuit Board Assembly
PCBA Factory Electronic Printed Circuit Board Assembly
Overview
Quick Details
Supplier Type:
OEM/ODM
Model Number:
HZPCB-20200824009
Place of Origin:
Guangdong, China
Product name:
PCBA Factory Electronic Printed Circuit Board Assembly
Material:
FR4 CEM1 CEM3 Hight TG
Application:
Digital Equipment
Type:
Customizable
Usage:
OEM Electronics
Solder mask:
Green. Red. Blue. White. Black.Yellow
Item:
ODM OEM LED PCBA
Solder mask color:
Black.Red.Yellow.White.Blue.Green
Place of origin:
Shenzhen
Supply Ability
Supply Ability:
10000 Piece/Pieces per Month
Video Description

PCBA Factory Electronic Printed Circuit Board Assembly

Product Description



PCB Assembly Capability:
Stencil Size: 736x736mm
Minimum IC Pitch: 0.2mm
Maximum PCB size: 1200x 500mm
Minimum PCB thickness: 0.25mm
Minimum chip size: 0201 (0.2x0.1)/0603 (0.6 x 0.3mm)
Maximum BGA size: 74x74mm
BGA ball pitch: 1.00mm (minimum), 3.00mm (maximum)
BGA ball diameter: 0.40mm (minimum), 1.00mm (maximum)
QFP lead pitch: 0.38mm (minimum), 2.54mm (maximum)
Volume:
One piece to low volume production quantities
Low cost first article builds
Schedule deliveries
Assembly type: Surface mount(SMT) assembly
DIP assembly
Mixed(surface mount and through hole) technology
Single or double sided placement
Cable assembly
Components type: Passive components:
As small as 0402 package
As small as 0201 with design review
Ball Grid Arrays(BGA):
As small as .5mm pitch
Parts procurements: Turnkey(we supply the parts)
Consigned(you supply the parts)
You supply some parts, we do the rest
Solder type: Leaded
Lead-free/ROHS compliant
Other capabilities: Repair/rework services
Mechanical assembly
Box build
Mold and plastic injection.



Delivery Time for PCB



Layer Prototype Mass Productions
Quick Turn  Unual Time (above 30 m2 )
2 24 hours 3-4 days 8-10 days
4 48 hours 5-6 days 10-12 days
6 72 hours 6-8 days 12-14 days
8 96 hours 8-10 days 14-16 days
10 120 hours 12-14 days 16-18 days
... ... ... ...



Delivery Time for PCBA



Order Conditions Standard Delivery Date The fastest Delivery Date
Prototype (<20 pcs)   2 days 8 hours
Small Volum (20-100 pcs)  3 days  12 hours
Medium Volum(100-1000 pcs)   6 days 24 hours
Mass productions (>1000 pcs)  Depends on BOM Depends on BOM
Detailed Images

Production Flow



Applications

Our Services

1. Who we are

PCB Manufacturer Flexibility Quality
Hongzhou, firstly established as a PCB manufacturer, has its own PCB factory with advanced manufacturing facilities, capable in fabricating up to 24 layers PCB boards. The factory is ISO9001 certified, with its PCB products UL approved and RoHS compliant. Your PCB cost and lead time can be reduced to buy PCBs from us. Hongzhou is highly customer oriented catering for customer's specific requirements. There are various kinds of available services, you can choose either full turn-key solutions or any single specific service. We can handle any size project from minimum quantity one piece to mass production. And we provide quick turn PCB and PCBA manufacturing service. Hongzhou fully understands the importance of quality for your projects. The quality control system is integrated in each step from preliminary PCB manufacturing to final PCBA packing, and a well-organized inspection and test procedure is performed to ensure the superior quality. All the products are 100% inspected for each shipment.




2. Support
Hongzhou aims to be the leading PCB manufacturer, and provide quality PCB products for electronic industry.

Layers 1-16 layers Min Board Thickness(2-layer) 0.2mm
Max Board Size 635 × 1100mm Min Board Thickness(4-layer) 0.6mm
Min Board Size 20 × 30mm Min Inner-layer Thickness 0.1mm
Min Trace 0.1mm Min Annular Ring 0.1mm
Min Space 0.1mm Min Hole Location Tolerance ±0.075mm
Min Hole Size 0.2mm Min Hole Size Tolerance ±0.05mm
Board Warp ≤ 1° Min Outer Dimension Tolerance ±0.1mm
Solder Mask Green, Yellow, Red, Black, Blue, White
Surface Finish HAL, HASL, Immersion Gold, Immersion Silver, Plating Gold, Plating Nickel, Plating Silver, Gold Finger, OSP
Board Material FR-4, High Tg FR-4, Halogen Free FR-4, Thick Copper FR-4, Aluminium Based, Rogers, Taconic
Acceptable file Gerber file(RS-274-X or RS-274-D with aperture list and drill files),Protel,PADS,POWERPCB,AutoCAD,ORCAD
CAM software Genesis, CAM350



3. PCB + Assembly
More and more of our existing PCB customers are now asking us for fully Assembled Printed Circuit Boards delivered to their door to take away all the time consuming stress of component procurement and assembly. In order to meet customers' requirements, Sunthone develops from a PCB manufacturer to a one-stop PCBA service provider, including PCB assembly, components sourcing, stencils, cable assembly and final product assembly and testing.

Available Services

  PCB Manufacturing

  PCB Assembly

  Components Sourcing

  SMT Stencils

  Cable Assembly

  PCBA Testing

  Final Product Assembly
Assembly Technologces

 SMT

THT

 Reflow Soldering

 Wave Soldering

 Hand Soldering

 Repair/Rework

 Mixed Assembly Technologies
Packaging & Shipping

FAQ
Q1.What is needed for PCB PCBA quotation?
A: PCB: Quantity, Gerber file and Technic requirements(material,surface finish treatment, copper thickness,board thickness ,...)
PCBA: PCB information, BOM, (Testing documents...)
Q2. What file formats do you accept for PCB PCBA production?
A: Gerber file: CAM350 RS274X
PCB file: Protel 99SE, P-CAD 2001 PCB
BOM: Excel (PDF,word,txt)
Q3. Are my files safe?
A: Your files are held in complete safety and security.We protect the intellectual property for our customers in the whole process.. All documents from customers are never shared with any third parties.
Q4. MOQ?
A: There is no MOQ in POE.We are able to handle Small as well as large volume production with flexibility.
Q5.Shipping cost?
A: The shipping cost is determined by the destination, weight, packing size of the goods. Please let us know if you need us to quote you the shipping cost.
Q6. What service do you have?
A: We mainly focus on PCB+Assembly+Components sourcing service. Additionally, we can also provide programming, testing, cables, enclosure assembly service.



Any inquiry about PCB Assembly for OEM service,please feel free to contact me.Thanks!
