POS Manufacturer Smart Android POS Machine All in One Pos Terminal HZ-CS10
POS Manufacturer Smart Android POS Machine All in One Pos Terminal HZ-CS10
Overview
Quick Details
Place of Origin:
Guangdong, China
Brand Name:
CS10
Model Number:
HZ-CS10-017
Product Name:
POS Manufacturer Smart Android POS Machine All in One Pos Terminal
CPU:
Quad-Core 1.35GHZ
OS:
Safedroid OS (based on Android 7.0 or 5.1)
All in one payment:
MSR/IC/NFC Card Reader
Functions:
Printer+Camera+GPS+SIM Card Slot
Battery:
Li-ion battery ,7.2V /2600mAH
Display:
5.5 inch TFT IPS LCD(1280*720)
Memory:
Li-ion battery ,7.2V /2600mAH
Interface:
Type C USB Port ,5V DC,2A
Communication:
4G/3G/2G/WIFI/Bluetooth
Supply Ability
Supply Ability:
10000 Unit/Units per Month
Video Description

POS Manufacturer Smart Android POS Machine All in One Pos Terminal HZ-CS10

Company Information

Smart & Reliable POS Terminal Solution-Supported by Hongzhou Group

Shenzhen Hongzhou Group was founded in 2005,ISO9001 2015 certified and China National Hi-tech enterprise.We are leading global self-service Kiosk,POS terminal manufacturer and solutions provider.



HZ-CS10 is the cutting-edge secure electronic payment terminal powered by Hongzhou Group,with safe-Android 7.0 operation system. It comes with a 5.5inch high definition colorful display, industrial level thermal printer and flexible configuration for various Barcode Scanner scenarios. A wide range of advanced connectivity options are supported for global 3G/4G network, as well as inbuilt NFC contactless, BT4.0 and WIFI.



Empowered by Quad-core CPU and massive memory, HZ-CS10 enables exceptionally fast processing of applications, and supports additional features for local customization including fingerprint scanner and fiscal module. It is your smart choice for one-stop payment and service.



HZ-CS10 is widely used in Shopping Mall,Supermarket,Chain Store,Restaurant,Hotel,Hospital,SPA,Cinema,

Entertainment,Tourism etc.

Product Description

Instructions for installment

1.Working condition: temperature -10℃~50℃,humidity 5%~95%,or the device will not be stable while working.

2. Connect the power adapter to device and connect the other side to a specific safe 220V/50HZ socket.

Warning: Do not put battery into fire; ensure no battery short circuit of Positive and negative pole; maximum charging voltage is 4.2V

3. Use the original power adapter only, other adapter may cause device work failure or damage.





Power ON/OFF operation

Power ON operation: after installed battery/connect power adapter, press power bottom for 2s, screen on, device goes to working mode; press power bottom for 2s, choose shutdown item, screen off, device goes to power off mode.

Magnetic card, IC card, SIM card, PSAM card, Micro SD card and contactless IC card

1. While swipe cards, swipe with constant speed, close to slot bottom, magnetic stripe should face the screen as the silk-screen directions, align at card slot, be sure magnetic cards is intact and in good condition.

2. Follow the silk-screen directions when insert IC cards, let the chip side upwards, insert carefully till you feel card be clamped, do not pull out during reading process.

3. Take off battery before install SIM card, PSAM card and Micro card, install them to corresponding slots.

4. Put card close to reading area while use contactless IC cards.



Instructions:

Stop the operation immediately if you notice below phenomenon:

1.Harsh noise while working.

2.Junk or water get into device accidentally.

3.Abnormal smell come out during work.

Stop immediately the operation and remove the battery, contact us or distributor at once.



Trouble Shooting and advised solution:

Fault phenomenon

Elimination methods

No display on screen

1. check if battery installed right

2. check if battery is enough for work

Cannot read card

1. check if card slot is clean

2. check if card has enough magnet info

Read magnetic card data incorrectly

1. swipe card with constant speed, close to slot bottom

2. magnetic stripe should face the screen, align at card slot

3. try to swipe card in another direction

IC card data read incorrectly

1. ensure the chip side is upward, card be inserted to the top

2. ensure IC card chip is safe and sound

NFC card data read incorrectly

1. ensure card has NFC function

2. ensure read card in NFC area

3. ensure card/mobile be placed smoothly and steady in NFC area

Camera failure

1. ensure camera not be covered

2. ensure if enough light for camera to work

Printer do not work

1. ensure paper is sealed correctly

2. check if it has right size paper, and installed right

3. check If low battery

Communication failure

1. check if sim card inserted, if card contactor clean

2. ensure there is signal

3. try to re-establish communication

Detailed Images

Functions

Packaging & Shipping

FAQ



Q1: What POS We provide?
A1: For financial/Commerce POS system, Wireless Handheld Cashless POS,
Android POS,2G/3G/GPS/GPRS/Wi-Fi/Bluetooth POS, but NO Desktop Cash POS.
Q2: Does your company accept  custom-made items?
A2: Yes, we can.We are a professional solution supplier for financial security & payment industry,
we provide diffierent solutions and products for diffierent customers.
Q3: How is Our POS's Quality?

A3: EMV Level 1&2, PCI 3.0 & 4.0, CE/RoHS/PBOC 2.0/China UnionPay, CCC,

and Network Access License and 100% test before shipment;

Q4: Do you Have Free SDK, Free Technical Support and After-sale Service?
A4:   1. Free SDK, Free Technical Support
        2.  7 * 24-hour service hotline: 0755-36869189;Online technical support by Email or Skype or Whatsapp;
        3.  Specialized process for repair or exchange of product required;
        4.  One Year QA warranty & Three Years After-sale Service Guarantee.
Q5: How About Your Shipping of POS?
A5: Delicate box with foam inside and shipping by air.
Q6: How Long is Your Lead Time?
A6: Within 1 for sample and within 45 for 500 to 5000 units after confirm payment.
Q7. How About Your POS Price?
A7: The more orders, the lower price.
Q8: How to Pay for our POS terminal?
A8: Payment: 50% pre-payment,        the rest of 50% is honored before shippment by T/T and 100% T/T for a sample.



Any inquiry about Smart POS,please feel free to contact me,Thanks!!!
