Company Advantages1. Hongzhou information kiosk is processed with fine soldering technique which directly determines the quality of the product. The soldering joints are carefully treated to ensure good electrical contact.
2. This product has electromagnetic compatibility. It has passed a comprehensive range of EMC tests such as conducted disturbances immunity testing, antenna screening effectiveness testing, and harmonic current emission testing.
3. This product has electromagnetic compatibility. Designed in accordance with the EMC Directive, it does not generate or is immune to electromagnetic disturbance.
4. When it comes to matters of fashion, this product is a good choice. It benefits those pursue fashion because it reflects their tastes in clothing.
5. This product can add an elegant appeal to a room. It also can reflect people's personalities and tastes in terms of interior decoration.
No. | Module | Description | QTY |
1 | Operation system | Windows 7 3 | 1 |
2 | Industrial PC | CPU:Intel i5 CPU;Capacity 4G DDR3;128GB SSD 10M/100M/1000M support TCP/IP;Interface: USB 8 pcs、COM interface 6 pcs. | 1 |
3 | 19 inch touch screen | Display resulotion:1280×1024;touch screen resulotion:4096*4096;anti dust、lifetime;50,000,000. | 1 |
4 | Touch pen | 1.Passive stylus; 2.Connection: the device has groove or hole design to store signature pen, signature pen | 1 |
5 | Bar-code scanner | System interface: USB to virtual serial port;
Support media type: support reading bar code information on paper, LCD, mobile phone screen and other media;
Reading Angle: 2d barcode 360 degrees to read qr code in any direction;
Readable bar width <=5MIL;The reading distance is 5-30cm;
Other requirements: use hard scanning code;
Decoding capability: decoding one-dimensional barcode, stacked/row 2d barcode and matrix 2d barcode; Support commonly used PDF417 2d barcode, Datamatrix 2d barcode,QR Code and other Code systems; Decoding time is less than 2 seconds; The light is slanting downward; | 1 |
6 | A4 laser printer | Type:Laser printer Size:A4 Maximun resulotion:600×600dpi
Speed:30ppm
Monthly print load:60000
Home page out time:<8.5s Standard carton:250 page,no lack of paper detection
Print media:Ordinary paper, ordinary thick paper, recycled paper, label paper, cover paper, envelope paper
Print:support USB | 1 |
7 | The fingerprint module | Capacitive fingerprinting device
Algorithm false recognition rate: ≤ 0.0001%
Rejection rate: ≤ 0.1% Login time: ≤ 1 second Comparison time: <1S(comparison time in fingerprint instrument) Search time: ≤ 1 second (when the number of fingerprints is 1000)
Alignment mode: 1:1 or 1:N alignment
Single fingerprint data volume: 512 bytes Fingerprint sensor: sensor acquisition life 1,000,000 times (1,000,000 times) Probe technique/probe position capacitive/dermis
Fingerprint admission module supports 180 degree adjustment or positive and negative installation Communication interface: rs-232 standard interface /USB standard interface | 1 |
8 | Contactless IC card + id card reader | Support the second-generation id card data reading function;
Support card type: A & B in accordance with iso-14443 standard, support unionpay PBOC3.0 communication protocol, support Mifare S50 S70 card; Support NFC reading function,
support non-connected IC card trading function;RF read-write distance: ≤ 50mm; | 1 |
9 | HD camera | Supports 1080P hd video collection;100DB super wide dynamic, suitable for complex light environment, especially strong backlight environment;Distortion free,
3 megapixel hd industrial lens. | 1 |
10 | High-speed photographic apparatus | Scanning height: 225mm-240mm A4 format Lens parameters: prime lens
Lens structure: 5MP 6G Perspective: 81 ° Resolution: maximum 2592X1944 to 640X480 Distortion: <1% Image control: brightness adjustment, exposure length adjustment, sharpness adjustment, color adjustment, gain control
Output standard: JPEG\BMP\GIF, etc | 1 |
11 | Operating keyboard | Ultra-thin metal wireless keyboard; 2.4g wireless and bluetooth connection is supported; | 1 |
12 | Loudspeaker | Used for audio data output, loudspeaker sound loud and clear; | 1 |
13 | Voice power amplifier board | Support hard switch, switch between the handle and power amplifier sound playback;Support horn amplifier, etc; | 1 |
14 | IO panel | Support to control the atmosphere lamp on and off, voltage DC12V, current 500mA, provide interface to industrial control board IO port control; | 1 |
15 | Cabinet and others | Including user operating indicator light, power box, dc fan, exhaust fan, USB Hub, network port, power port, USB interface, power switch, silk screen logo,
guide rail, module card slot frame,cabinet, etc. | 1 |
※ Innovative & smart design, elegant looking, anti-corrosion power coating;
※ Ergonomically and compact structure, user friendly, easy for maintenance;
※ Anti-vandalism, dust-proof, high safety performance;
※ Rugged steel frame and overtime running, high precision, high stability & reliability;
※ Cost-effective, customer-oriented design, the applicable environmental.
Beauty appearance, high quality
Easy operation with multi- function
Company Features1. Lots of people choose Hongzhou for information kiosk , which owns to Hongzhou Smart Tech Co.,Ltd's leading status in global market.
2. Hongzhou Smart Tech Co.,Ltd has a complete production line and advanced testing method.
3. As a reliable and reputable manufacturer and supplier, we will actively foster sustainable practices. We take the environment seriously and have made changes in aspects from the production to the selling of our products. We implement our environmental sustainability strategy by reducing our own environmental impacts such as the reduction of energy use and water.
