Company Advantages1. The materials used in Hongzhou kiosk ticketing system are guaranteed high quality. The materials are strictly tested in terms of moisture and fire resistance, complying with the requirements in KCMA.
2. The operation of our ticket kiosk machine is very simple, even inexperienced worker can learn it in short time. .
3. Hongzhou Smart Tech Co.,Ltd ensures that its products absolutely meet the quality standards.
4. Rich business experience, strong R&D team, and preferential product prices are examples of Hongzhou Smart Tech Co.,Ltd's strength.
Components List |
No | Components | Brand / Model | Main Specifications |
1 | Industrial PC System | Industrial PC | Mother Board | Intel H81; Integrated Network card and Graphic card |
CPU | Intel G3260 |
RAM | 4GB |
HDD | 500G |
Interface | 14*USB; 12*COM; 1*HDMI; 1*VGA; 2*LAN; 1*PS/2; 1*DVI; |
PC Power Supply | HUNTKEY |
2 | Operation System |
| Windows 7(without license) |
3 | Operation panel | Auo | Screen Size | 21 inch |
Pixel Number | 1280x1024 |
Brightness | 350cd/m2 |
Contrast | 1000∶1 |
Display Colors | 16.7M |
Viewing Angle | 85°/85°/80°/80° |
LED Life Time | Min. 40000hrs |
4 | Touch Screen | EG19 | Screen Diagonal | 19inch |
Touch technology | Capacitive |
Touch Points | Multi-finger |
Glass Hardness | 6H |
Min.Reprot Rate | 100points/sec |
Operation Conditions | -40°C~+85°C at Min 20% to Max 90%RH |
5 | Printer | Epson-MT532 | Printer Method | Thermal printing |
Print width | 80mm |
Speed | 250mm/sec(Max) |
Resolution | 203dpi |
Print length | 100KM |
Autocutter | included |
6 | Power Supply | RD-125-1224 | AC input voltage range | 100‐240VAC |
Frequency | 50Hz to 60Hz |
Output over current protection | 110~130% |
Operating temp. & humidity | ‐10~+50,20%~90%RH (noncondensing) |
7 | Ticket printer | K301 | Printer Method | Thermal printing |
Resolution | 203 dpi |
Width | 80mm |
Speed | 120mm-200mm/s |
Paper thickness | 0.1-0.3mm flod paper |
Automatic cutter | 1,000,000 life time(All cut) |
8 | Camera | C170 | Photosensitive element | CMOS camera |
Camera pixel | 3 million |
Interface type | usb2.0,No need to drive |
Focusing mode | Autofocus |
Fold other parameters | Features snapshot button anti-theft function |
9 | Speaker | OP‐100 | Dual channel amplified speakers for Stereo , 8Ω 5W. |
10 | KIOSK Cabinet | Hongzhou | Dimention | decided when finish production |
Color | Optional by customer |
1. The material of outer metal cabinet is durable 1.5mm thickness cold-roll steel frame; |
2. The design is elegant and easy to install and operate; Moistureproof,Antirust, Anti-acid, Anti-dust,Static free; |
2.Color and LOGO are upon customers' requests. |
11 | Accessories | Security Lock for anti theft , tray for easy maintenance,2 ventilation fans, Wire-Lan Port; Power sockets for electricity, USB ports;Cables, Screws, etc. |
|
12 | Packing | Security Packing Method with Bubble Foam and Wooden Case |
|
※ Innovative & smart design, elegant looking, anti-corrosion power coating
※ Ergonomically and compact structure, user friendly, easy for maintenance
※ Anti-vandalism, dust-proof, high safety performance
※ Rugged steel frame and overtime running, high precision, high stability & reliability
※ Cost-effective, customer-oriented design, the applicable environmental
Company Features1. As a(n) kiosk ticketing system manufacturing enterprise, Hongzhou Smart Tech Co.,Ltd is continually developing and providing innovative and quality products for customers.
2. We are not the only one company to produce ticket kiosk machine, but we are the best one in term of quality.
3. We always adhere to the core idea of "customer-center and human-oriented". This makes our company well recognized and accepted by industry customers. We are committed to achieving a totally safe, sustainable waste management way. We will professionally process the wastes and control the carbon footprint in the transport of production wastes. With a goal to improve customer satisfaction, we will hire a cultural consultant to help guide us in creating marketing content that takes into account culture and any linguistic nuances. We believe this will help us work better with customers from different backgrounds. We actively promote the progress of projects in the field of environmental protection. We recycle and reuse most of the wastes and utilize the rest of the waste to generate energy, aiming to develop a cyclic economy.
