Company Advantages1. Hongzhou ticketkiosk is manufactured as per the international quality norms and well-defined industry parameters.
2. Its developing requires stringent testing to ensure quality and performance. Only those that pass rigorous tests will go to the marketplace.
3. The product is cost-effective, efficient, and robust enough to handle the rigorous demands of the refrigeration industry such as food and beverage sector.
4. Since the product is able to maintain its original brightness throughout the lifespan over time, people can use it for a long time without replacing.
Components List |
No | Components | Brand / Model | Main Specifications |
1 | Industrial PC System | Industrial PC | Mother Board | Intel H81; Integrated Network card and Graphic card |
CPU | Intel G3260 |
RAM | 4GB |
HDD | 500G |
Interface | 14*USB; 12*COM; 1*HDMI; 1*VGA; 2*LAN; 1*PS/2; 1*DVI; |
PC Power Supply | HUNTKEY |
2 | Operation System |
| Windows 7(without license) |
3 | Operation panel | Auo | Screen Size | 21 inch |
Pixel Number | 1280x1024 |
Brightness | 350cd/m2 |
Contrast | 1000∶1 |
Display Colors | 16.7M |
Viewing Angle | 85°/85°/80°/80° |
LED Life Time | Min. 40000hrs |
4 | Touch Screen | EG19 | Screen Diagonal | 19inch |
Touch technology | Capacitive |
Touch Points | Multi-finger |
Glass Hardness | 6H |
Min.Reprot Rate | 100points/sec |
Operation Conditions | -40°C~+85°C at Min 20% to Max 90%RH |
5 | Printer | Epson-MT532 | Printer Method | Thermal printing |
Print width | 80mm |
Speed | 250mm/sec(Max) |
Resolution | 203dpi |
Print length | 100KM |
Autocutter | included |
6 | Power Supply | RD-125-1224 | AC input voltage range | 100‐240VAC |
Frequency | 50Hz to 60Hz |
Output over current protection | 110~130% |
Operating temp. & humidity | ‐10~+50,20%~90%RH (noncondensing) |
7 | Ticket printer | K301 | Printer Method | Thermal printing |
Resolution | 203 dpi |
Width | 80mm |
Speed | 120mm-200mm/s |
Paper thickness | 0.1-0.3mm flod paper |
Automatic cutter | 1,000,000 life time(All cut) |
8 | A4 Size printer | HP M403d | Printer Method | Laser printer |
Paper processing / output | 100 page out carton |
Paper layout | Single page feed |
Speed | Up to 18 pages per minute |
Operating temperature range | 15 degrees C to 32.5 degrees C |
Power waste | 360 watt (print), 1.4 watt (ready), 0.9 watt (automatic shutdown), 0.6 watts (manual shutdown) |
Power requirements | 220 V input voltage: 220 to 240 volts alternating current (+/-10%), 50 Hz (+/-2 Hz), 6 a. |
9 | Camera | C170 | Photosensitive element | CMOS camera |
Camera pixel | 3 million |
Interface type | usb2.0,No need to drive |
Focusing mode | Autofocus |
Fold other parameters | Features snapshot button anti-theft function |
10 | RFID Card Reader | CFRS-102 | Support | ID: EM4100,4200,TK4100and compatible card
IC: Mifare one s50/S70,etc |
11 |
|
| Frequency | 125KHz,13.56MHz |
12 | Speaker | OP‐100 | Dual channel amplified speakers for Stereo , 8Ω 5W. |
13 | KIOSK Cabinet | Hongzhou | Dimention | decided when finish production |
Color | Optional by customer |
1. The material of outer metal cabinet is durable 1.5mm thickness cold-roll steel frame; |
2. The design is elegant and easy to install and operate; Moistureproof,Antirust, Anti-acid, Anti-dust,Static free; |
2.Color and LOGO are upon customers' requests. |
14 | Accessories | Security Lock for anti theft , tray for easy maintenance,2 ventilation fans, Wire-Lan Port; Power sockets for electricity, USB ports;Cables, Screws, etc. |
|
15 | Packing | Security Packing Method with Bubble Foam and Wooden Case |
|
※ Innovative & smart design, elegant looking, anti-corrosion power coating
※ Ergonomically and compact structure, user friendly, easy for maintenance
※ Anti-vandalism, dust-proof, high safety performance
※ Rugged steel frame and overtime running, high precision, high stability & reliability
※ Cost-effective, customer-oriented design, the applicable environmental
Company Features1. Hongzhou Smart Tech Co.,Ltd is a high-tech enterprise with strong R&D strength and modern operation and management concept.
2. Hongzhou Smart Tech Co.,Ltd's technical force is abundant, and the examination method is perfect.
3. We put great emphasis on maintaining the highest standards at every stage of our production and we are continuously improving the way our processes impact on our customers, consumers and the world around us. We are committed to improving our brand recognization. By demonstrating a positive image to clients and partners, we actively partake in various business activities to make our brand known more by people. We are committed to extending our responsible and sustainable practices to every aspect of our business, from our own quality control to the relationships we have with our suppliers. We perform social responsibility in our business operation. One of our primary focus is the environment. We take steps to reduce carbon footprints, which is good for both the company and society.
