Company Advantages1. The manufacture of Hongzhou pos card machine is of professionalism. The process mainly includes the following stages: the procurement of metal materials, fabrication of the frame, machining and assembly of component parts, and commissioning. Reliable and tested components are seamlessly integrated and placed for optimal serviceability
2. The perfect customer service of Hongzhou Smart Tech Co.,Ltd is a powerful advantage in market competition. The product features a sleek and durable enclosure, providing a contemporary and sophisticated user interface
3. The life cycle of this product has been greatly extended. The product has been certified under UL
4. All the
smart pos are reliable in property and reputably appraised by customers. It serves as a durable, modern, interactive billboard to convey any intended message in a powerful way
5. This produt complies with regulations and standards, helping avoid failures and recalls. The attractive curved face and trim options can be customized to complement any environment
Empowered by Quad-core CPU and massive memory, HZ-CS10 enables exceptionally fast processing of applications, and supports additional features for local customization including fingerprint scanner and fiscal module. It is your smart choice for one-stop payment and service.
Ø Safedroid OS, Based on Android 5.1 or 7.0 O/S;
Ø 5.5 inch TFT IPS LCD, resolution 1280*720
Ø Built-in high speed thermal printer , with over 50Km print life
Ø Full bands for global coverage: 4G/3G/2G,WLAN,VPN
Ø Authentec,508dpi fingerprint module for biometric identification
Ø Dual camera for quickly QR code scan & Honeywell 2D scanner as option
Ø One-stop payment of MSR/IC/NFC, with PCI PTS 4.X, EMV L1&L2 certified
DEMO SHOW: https://youtu.be/EnVZUunmeMk
No. | Basic Module | Main Specifications |
1 | Basic Characteristics | OS | Safe android OS (based on Android 5.1 or 7.0 O/S) |
2 | CPU | Quad-Core 1.35GHZ |
3 | ROM | 8GB ROM EMMC |
4 | RAM | 1G RAM LPDDR3 |
5 | Display | 5.5 inch TFT IPS LCD,resolution 1280*720 |
6 | Panel | Ultra sensitive capacitive touch screen, can work with gloves and wet fingers |
7 | Dimensions | 206mmX84mmX32mm (max 56mm) |
8 | Weight | 530g(Battery included) |
9 | Keys | 3 Physical keys:1 ON/OFF KEY,2 Shortcut keys |
10 | 3 Virtual keys:Menu,Home,Back |
11 | Input | Chinese/English ,and supports handwriting and soft keyboard |
12 | Radio Communication | WIFI | IEEE 802.11 a/b/g/n ,support dual Band 2.4GHZ and 5GHZ |
13 | Bluetooth | BT 4.0 LE +EDR |
14 | 4G | TD-LTE:Band38, Band39, Band40, Band41 |
15 | FDD-LTE:Band1,Band3,Band7,Band8,Band20 |
16 | 3G | UMTS(WCDMA)/HSPA+:Band1,Band8,Band2,Band5 |
17 | CDMA EV-DO Rev.A:800MHZ |
18 | TD-SCDMA:Band34,Band39 |
19 | 2G | GSM/GPRS/EDGE:850/900/1800/1900MHZ |
20 | Payment | Magcard reader | Supports ISO7811/7812/7813, and supports triple |
21 | track (tracks 1/2/3), bi-directional |
22 | Smart Card reader | Supports ISO7816 standard |
23 | Contactless Card reader | Supports 14443A / 14443B |
24 | Expansion and peripherals | Printer | High-Speed Thermal Printer ; |
25 | 58mm printing paper ; |
26 | 40mm paper roll |
27 | Camera | 5MP camera with LED flash and auto-focus function |
28 | Satellite Positioning | GPS, Supports A-GPS |
29 | Audio | Speaker ,Microphone,Earphone |
30 | Interfaces | Micro SD Card Slot | 1 PCS |
31 | SIM Card Slot | 2 PCS MICRO SIM |
32 | PSAM Card Slot | 2 PCS Conforms to ISO7816 standard |
33 | USB Port | 1PCS TYPE C USB |
34 | Power | Battery | Li-ion battery ,7.4V /2600mAH |
35 | Charging Port | Type C USB Port ,5V DC,2A |
36 | Environment | Operating Temperature | -10°C to 50°C |
37 | Storage Temperature | -20°C to 70°C |
38 | Humidity | 5% to 95% Relative Humidity, Non-Condensing |
39 | Certification | Electromagnetic | CCC,CE,FCC |
40 | Payment | PCI PTS 4.X ,EMV L1&L2 |
41 | Optional | Fingerprint | Semiconductor capacitance |
42 | 14.4mm x 10.4mm imaging area |
43 | 208 x 288 pixel array, |
44 | Crossmatch FBI certified |
45 | Authentec,508dpi |
46 | Front camera | 2 Megapixel Fixed Focal Camera |
47 | Barcode Scanner | Honeywell 2D Image Engine, Support 1D and 2D symbologies |
48 | Satellite Positioning | GLONASS, Bei-Dou satellite navigation system |
49 | Fiscal Module | Russian format |
※ Safedroid OS, Based on Android 7.0 or 5.1 OS
※ 5.5 inch TFT IPS LCD, resolution 1280*720
※ Built-in high speed thermal printer , with over 50Km print life
※ Full bands for global coverage: 4G/3G/2G,WLAN,VPN
※ Authentec,508dpi fingerprint module for biometric identification
※ Dual camera for quickly QR code scan & Honeywell 2D scanner as option
※ One-stop payment of MSR/IC/NFC, with PCI PTS 5.X, EMV L1&L2 certified
Main module:
Magcard reader,Smart Card reader,Contactless Card reader,Printer,Camera,Fingerprint,Barcode Scanner
Accessories:
Type-C USB Cable, Battery, Charger Head, Printer Paper
Company Features1. Over the years, Hongzhou Smart Tech Co.,Ltd has stood firmly in the domestic markets. We are known to have competitive strength in manufacturing smart pos . Our factory insists on quality management policy. From materials procurement to assembly, all production stages are required to strictly meet the related national standards.
2. We have a team of professionals. They have special insight into the way of developing and designing products that perfectly cater to the market, which helps the company earn the market.
3. We have explored new overseas markets in recent years, mainly including USA, Russia, New Zealand, and so on. We have grown bigger because of continuous products innovation and quality products that we have offered to these customers. Hongzhou Smart Tech Co.,Ltd has made unremitting efforts to create more perfect products and technologies. Contact!
