PCB PCBA Service One Stop Electronic Manufacturing Service
PCB PCBA Service One Stop Electronic Manufacturing Service
PCB Assembly Capability:
|
Stencil Size: |
736x736mm |
|
Minimum IC Pitch: |
0.2mm |
|
Maximum PCB size: |
1200x 500mm |
|
Minimum PCB thickness: |
0.25mm |
|
Minimum chip size: |
0201 (0.2x0.1)/0603 (0.6 x 0.3mm) |
|
Maximum BGA size: |
74x74mm |
|
BGA ball pitch: |
1.00mm (minimum), 3.00mm (maximum) |
|
BGA ball diameter: |
0.40mm (minimum), 1.00mm (maximum) |
|
QFP lead pitch: |
0.38mm (minimum), 2.54mm (maximum) |
|
Volume: |
One piece to low volume production quantities Low cost first article builds Schedule deliveries |
|
Assembly type: |
Surface mount(SMT) assembly DIP assembly Mixed(surface mount and through hole) technology Single or double sided placement Cable assembly |
|
Components type: |
Passive components: As small as 0402 package As small as 0201 with design review Ball Grid Arrays(BGA): As small as .5mm pitch |
|
Parts procurements: |
Turnkey(we supply the parts) Consigned(you supply the parts) You supply some parts, we do the rest |
|
Solder type: |
Leaded Lead-free/ROHS compliant |
|
Other capabilities: |
Repair/rework services Mechanical assembly Box build Mold and plastic injection. |
