X86 Industrial Motherboard UJ4125T-6C1L with Mini ITX Independent CPU
USKYUT-6CD8
Intel® 6th Skylake-U /7th Kabylake-U processor optional, 32GB DDR4, supports triple display, 10USB, 1 SATA 3.0 and 6 COM
Specification List
|
Model No. |
UJ4125T-6C1L |
|
Category |
X86 Motherboard |
|
Chipset |
Intel® SOC |
|
CPU |
Intel UHD Graphics 600 |
|
GPU |
Intel Celeron J4125 Processor, Quad Core |
|
Display output |
Support VGA、HDMI/EDP2、LVDS/EDP1, Support Triple Display |
|
Multi Display |
EDP1+EDP2+VGA LVDS+HDMI+VGA, LVDS+EDP2+VGA EDP1+HDMI+VGA |
|
USB |
2*USB3.0 7*USB2.0 |
|
Memory |
1*SO-DIMM DDR4, Max8GB |
|
Audio |
Onboard Realtek ALC269HD |
|
Network |
onboard 1 *RTL8111H/RTL8111G Gigabit Ethernet Card |
|
Storage |
1*SATA3.0 interface, 1* mSATA |
|
WIFI |
2*MINI-PCIE(for WIFI ) |
|
COM |
2/6*COM（1*485 ）(Option: 2*COM) |
|
Rear I/O |
2*USB3.0 1*VGA 1*HDMI 2*USB 2.0 (LAN2 and 2*USB2.0 optional) 1*LAN 1N* HP_OUT interface 1*MIC-IN 1*DC |
|
Internal I/O |
1* EDP2 PIN 1* VGA_H PIN 1* F-AUDIO PIN 1* SPEAKER PIN 1* F_USB3.0 PIN (expandable 2* USB3.0) 2* F_USB2.0 PIN (expandable 4* USB2.0) 1* SATA PIN 1* SATA_PWR PIN 1* JPS2 PIN 1* J_PRINT PIN 1* F_PANEL PIN 2* COM PIN (Suppoorts 1* RS485 option, COM1 and COM2 support live reversible DCD/5V/12V) 1* COM_CONN PIN (4* COM RS232) 1*GPIO PIN 1* LVDS PIN 1* EDP PIN 1* INVERT PIN 1* LCTL PIN 1* 4 PIN ATX Socket |
|
BIOS |
AMI BIOS |
|
Power supply |
DC/ATX 4PIN 12V Power Supply |
|
Cooling |
Equipped wit CPU Heatsink |
|
Operating environment |
Temperature: 0~60℃(working); -20~75℃(Storage) |
|
Size |
170X170MM |
USKYUT-6CD8 motherboard adopts Intel® 6th Skylake-U /7th Kabylake-U Series i3/i5/i7 processor. It supports max. 32GB DDR4 memory, three display including VGA 、HDMI/EPD2、LVDS/EDP1 (synchronous/asynchronous display), and is onboarded with 2* LAN, 10 USB Thread, 1 SATA, 6 COM and 1 PCIe supports Wifi+Bluetooth / 4G Module. It is your best choice for human-computer interaction and industrial control projects.
We has a world-class industrial motherboard production workshop. we adopt dust-free workshops to test every index of the products to ensure the precision and efficiency of the products, so as to provide customers with the highest quality and reliable industrial computer motherboards.
