Shenzhen medical equipment pcb&pcba printed circuit board pcba factory
5.0
design customization
Please fill out the form below to request a quote or to request more information about us. Please be sure to upload customized requirement documents or pictures, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Please fill out the form below to request a quote or to request more information about us. please be as detailed as possible in your message, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Products Description
PCB Item | Manufacture Capacity | |
Layer Counts | 1--20L | |
Base Material | FR4,High-TG FR4,CEM3,aluminum,High Frequency(Rogers,Taconic,Aron,PTFE,F4B) | |
Material Thickness(mm) | 0.40, 0.60, 0.80, 1.00, 1.20, 1.50, 1.60, 2.0, 2.4, 3.2 | |
Max board size(mm) | 1200x400mm | |
Board Outline Tolerance | ±0.15mm | |
Board Thickness | 0.4mm--3.2mm | |
Thickness Tolerance | ±8% | |
Minimum line/space | 0.1mm | |
Min Annular Ring | 0.1mm | |
SMD Pitch | 0.3mm | |
Holes | ||
Min Hole Size(mechanical) | 0.2mm | |
Min Hole Size(laser hole) | 0.1mm | |
Hole Size Tol (+/-) | PTH:±0.075mm;NPTH: ±0.05mm | |
Hole Position Tol | ±0.075mm | |
Plating | ||
HASL/LF HAL | 2.5um | |
Immersion Gold | Nickel 3-7um Au:1-5u'' | |
Surface Finish | HAL,ENIG,Plated Gold,Immersion Gold,OSP | |
Copper | ||
Copper Weight | 0.5--6oz | |
Color | ||
Solder mask | Green, Blue, Black, White, Yellow, Red, Matt Green, Matt Black, Matt Blue | |
Silk screen | White, Black, Blue,Yellow | |
Acceptable File Format | Gerber file,Powerpcb,CAD,AUTOCAD,ORCAD,P-CAD,CAM-350,CAM2000 | |
Certificate | ROSH,ISO9001,UL | |
PCB Assembly Capability
Stencil Size | 736x736mm |
Minimum IC Pitch | 0.2mm |
Maximum PCB size | 1200x 500mm |
Minimum PCB thickness | 0.25mm |
Minimum chip size: | 0201 (0.2x0.1)/0603 (0.6 x 0.3mm) |
Maximum BGA size: | 74x74mm |
BGA ball pitch: | 1.00mm (minimum), 3.00mm (maximum) |
BGA ball diameter: | 0.40mm (minimum), 1.00mm (maximum) |
QFP lead pitch: | 0.38mm (minimum), 2.54mm (maximum) |
Volume: | One piece to low volume production quantities Low cost first article builds Schedule deliveries |
Assembly type: | Surface mount(SMT) assembly DIP assembly Mixed(surface mount and through hole) technology Single or double sided placement Cable assembly |
Components type: | Passive components: As small as 0402 package As small as 0201 with design review Ball Grid Arrays(BGA): As small as .5mm pitch |
Parts procurements: | Turnkey(we supply the parts) Consigned(you supply the parts) You supply some parts, we do the rest |
Solder type: | Leaded Lead-free/ROHS compliant |
Other capabilities: | Repair/rework services Mechanical assembly Box build Mold and plastic injection. |
Details Images
OEM/ODM/EMS Services for PCBA:
* PCBA, PCB Board assembly: SMT & PTH & BGA
* PCBA and enclosure design
* Components sourcing and purchasing
* Quick prototyping
* Plastic injection molding
* Metal sheet stamping
* Final assembly
* Test: AOI, In-Circuit Test (ICT), Functional Test (FCT)
* Custom clearance for material importing and product exporting
* PCBA, PCB Board assembly: SMT & PTH & BGA
* PCBA and enclosure design
* Components sourcing and purchasing
* Quick prototyping
* Plastic injection molding
* Metal sheet stamping
* Final assembly
* Test: AOI, In-Circuit Test (ICT), Functional Test (FCT)
* Custom clearance for material importing and product exporting
Capability - SMT
* Lines 9(5 Yamaha,4KME)
* Capacity 52 million placements per month
* Max Board Size 457*356mm.(18”X14”)
* Min Component size 0201-54 sq.mm.(0.084 sq.inch),long connector,CSP,BGA,QFP
* Speed 0.15 sec/chip,0.7 sec/QFP
Capability - PTH
* Lines 2
* Max board width 400 mm
* Type Dual wave
* Pbs status Lead-free line support
* Max temp 399 degree C
* Spray flux add-on
* Pre-heat 3
* Lines 9(5 Yamaha,4KME)
* Capacity 52 million placements per month
* Max Board Size 457*356mm.(18”X14”)
* Min Component size 0201-54 sq.mm.(0.084 sq.inch),long connector,CSP,BGA,QFP
* Speed 0.15 sec/chip,0.7 sec/QFP
Capability - PTH
* Lines 2
* Max board width 400 mm
* Type Dual wave
* Pbs status Lead-free line support
* Max temp 399 degree C
* Spray flux add-on
* Pre-heat 3
