Electronic SMT/DIP Assembly PCB Board Assembly
Electronic SMT/DIP Assembly PCB Board Assembly
Overview
Quick Details
Place of Origin:
Guangdong, China
Brand Name:
OEM/ODM
Model Number:
HZ-PCB023
Base Material:
FR-4
Copper Thickness:
0.25 Oz -12 Oz
Board Thickness:
1.6mm-3.2mm
Min. Hole Size:
0.20mm
Min. Line Width:
0.1 0mm
Min. Line Spacing:
0.1mm4mil)
Surface Finishing:
HASL, HASL,Enig,OSP,Immersion Au,AG,Sn
Product name:
Electronic SMT/DIP Assembly PCB Board Assembly
Material:
FR4 CEM1 CEM3 Hight TG
Layer:
1-18
Customized:
Customized
PCBA QC:
X-ray,Aoi Test,Function Test(100% Test)
Origin:
Shenzhen, Guangdong
Layers:
Multilayer
Certificate:
ISO/RoHS/TS16949
HS Code:
8534009000
Supply Ability
Supply Ability:
100000 Piece/Pieces per Month

Electronic SMT/DIP Assembly PCB Board Assembly

Company Information

Product Description

 PCB Assembly Capability:

Stencil Size:

736x736mm

Minimum IC Pitch:

0.2mm

Maximum PCB size:

1200x 500mm

Minimum PCB thickness:

0.25mm

Minimum chip size:

0201 (0.2x0.1)/0603 (0.6 x 0.3mm)

Maximum BGA size:

74x74mm

BGA ball pitch:

1.00mm (minimum), 3.00mm (maximum)

BGA ball diameter:

0.40mm (minimum), 1.00mm (maximum)

QFP lead pitch:

0.38mm (minimum), 2.54mm (maximum)

Volume:



One piece to low volume production quantities

Low cost first article builds

Schedule deliveries

Assembly type:



Surface mount(SMT) assembly

DIP assembly

Mixed(surface mount and through hole) technology

Single or double sided placement

Cable assembly



Components type:



Passive components:

As small as 0402 package

As small as 0201 with design review

Ball Grid Arrays(BGA):

As small as .5mm pitch



Parts procurements:



Turnkey(we supply the parts)

Consigned(you supply the parts)

You supply some parts, we do the rest



Solder type:



Leaded

Lead-free/ROHS compliant

Other capabilities:



Repair/rework services

Mechanical assembly

Box build

Mold and plastic injection.

Detailed Images

Applications

Product process

Equipment

Packaging & Shipping

Our Services
